RGBW Indoor High Density LED Strip Light — 12V, 6W/ft, IP20

Description

Part of our Professional Series, this high-density 12V RGBW LED strip combines vibrant RGB color-changing light with a dedicated 3000K Warm White channel. It provides the flexibility to create saturated colors and dynamic effects while still producing useful warm white light for everyday illumination.

RGBW Configuration

RGB Color + Dedicated Warm White

Unlike a standard RGB strip that creates white by mixing red, green, and blue, RGBW adds a dedicated 3000K white channel. This gives you vivid color-changing effects plus a more natural warm white light from the same strip.

Color Control

An RGBW controller is required to independently control the red, green, blue, and white channels. Compatible controllers allow you to mix colors, adjust brightness, select the dedicated white channel, and create dynamic lighting effects.

Lengths & Cutting

Available in 3 ft, 6 ft, 9 ft, 12 ft, and full 16.4 ft (5m) roll lengths. The strip can be cut every 2.81 inches at the marked copper cut points. Maximum continuous run length is 16.4 ft.

Installation & Connections

RGBW strip sections can be connected with compatible 5-pin solderless connectors or by soldering multi-conductor wire between sections. The maximum continuous run is 16.4 ft; longer installations should use additional power feeds or be wired in parallel to minimize voltage drop.

Each strip includes a 5-pin RGBW connection on one end. Additional connections can be made using compatible connectors or by soldering.

Power & Control

A 12V DC power supply and RGBW controller are required. The strip uses approximately 16.8W/m, with a full 16.4 ft (5m) roll drawing approximately 84W. Size the power supply for the total connected load with appropriate additional capacity.

Power by Length

Important: The shorter-length values above are approximate. For a full 16.4 ft (5m) roll, use the published 84W full-roll power when sizing the power supply.
