RGBW LED Flex Strips - Color Changing RGB + White

More images

Regular Price: $29.75
Sale Price: $27.99
You Save: $1.76
PART #: R6096IP20RGBWxx
VOLUME DISCOUNTS
PCS
% OFF
10 - 49
5%
50 - 99
7.5%
100 - 249
10%
250 - 499
20%
Shipping Information*
First Class
FREE
Fedex 2-Day
$7.99
FedEx Ground
$8.99
UPS Ground
$9.99
FedEx Express
CALC

Purchase

0 PCS IN-STOCK

ORDER BY 3PM EST FOR
SAME DAY SHIPPING
  • Color Changing + Whites!
  • 30 LEDs per FT!
  • Max. Length - 16.4 ft. (5M)

Product Details

LED Density: High Density - 96 LEDs/M Colors: Color-Changing RGB + Warm White 3000K
LEDs: Alternating 3-in-1 RGB + White LEDs Power: 24VDC
Wattage: 23 Watts/M (115/Reel) Mounting: Doubled-Sided 3M Tape
Cuttable: Every 12 LEDs (4.92") Custom Lengths: 3-Foot Increments up to 16.4-Feet (Full Reel 5M)
Size: 12mm Wide X 1mm Tall Connection: 5-pin RGB+W connector


Description

LED Strip Light GuideThe RGB+W LED Strip Light is our first strip offering color changing + white LEDs. This top of the line strip combines two powerful strip lights into one: alternating RGB color changing LEDs plus single color high brightness white LEDs. This LED strip is for those spaces that you want total control over, the lights mix to make any color you can imagine including a quality warm-white when you need it. The strips are easy to use, making it possible to install with minimal knowledge on the electrical side. The flexible construction of the strip combined with the 3M adhesive backing and cut-to-size design make it convenient to elevate any indoor space.

Density

Density # of LEDs Wattage Cuttable Max Run
M Reel M Reel
High (HD) 96 480 23W 115W 4.92" 1 Reel

Controlling Colors

In order to run RGBW Flex Strip you will need the RGBW Touch Controller.

Lengths

To avoid buying more than necessary we offer custom length LED light strips in 3-foot increments up to 16.4 feet long (1 full reel). However, we realize that all applications have different needs which is why the strips can be cut after every 12 LEDs which equates to ever 4.92". There is a thin black line over solder pads, which marks where you are to cut the strips. Max Run Length = 1 full reel - 16.4ft.

End-to-End Connections

cutting and connecting led flex strip

When there is a break in your application you can still run one strip to another using 20-24 gauge wire or LED strip connectors. TAKE NOTE: the RGBW Strips maximum run length is 16.4 feet (1 reel). After the maximum run length the voltage drop becomes too great and you will lose light and efficiency from your system. If your application needs more than the maximum run length you will have to get another power supply or run wire from the extra strip directly back to the first power supply (wiring in parallel).

Connections can be made by soldering wire in between strips or by using solderless clamps (see right). Only one end of the strips come with a 5-Pin connector on it so if you want to make more connections you will need to solder or use strip connectors. Here is a good tutorial on wiring the strips together if you'd like more information.

Power

A 24-volt DC Power Supply is required to run these LED Strip lights (along with an RGBW controller). The Strips run at 23W per meter so a full reel is 115 Watts of power. Please make sure you get a Power Supply suitable enough for your needs.

Need Help with LED Strips?

Guide to LED Strip Lights

DIY Tutorial: Accent Lighting with LED Flex Strips

DIY Tutorial: Setting Up Color Changing LED Strips
