COB Color Indoor LED Strip Light — 24V, 5W/ft, IP20

Description

Part of our Architectural Series, this 24V COB single-color LED strip delivers smooth, dot-free red, green, or blue light for clean indoor accent lighting. Its continuous light-emitting surface eliminates the visible LED dots commonly found with traditional SMD strips.

Available Colors

Smooth, Dot-Free COB Light

COB technology packs 512 LEDs per meter into a continuous light-emitting surface, eliminating distinct LED hot spots and producing a smooth line of color. The wide 180° viewing angle makes these strips especially well suited for displays, signage, shelving, backlighting, architectural accents, and installations where the strip itself may be visible.

Lengths & Cutting

Available in 3 ft, 6 ft, 9 ft, 12 ft, and full 16.4 ft (5m) roll lengths. The strip can also be cut every 2.46 inches at the marked copper cut points.

Installation & Connections

COB strip sections can be connected by soldering wire between sections or with compatible solderless connectors. The maximum continuous run is 32.8 ft; longer installations should use additional power feeds or be wired in parallel to minimize voltage drop.

Shorter custom lengths include a power connection on one end, while full 16.4 ft rolls include connections on both ends.

Power & Dimming

A 24V DC power supply is required. Use the Power by Length table below to size the power supply for each continuous strip run. The strip is PWM dimmable using a compatible 24V dimmer installed between the power supply and LED strip.

Power by Length

Important: Power draw is not linear over longer strip runs. Voltage drop along the strip reduces the actual wattage as the run gets longer, so use the measured values above rather than multiplying the short-length watts-per-foot value across the entire run when sizing a power supply.
