INDUS™ 1-Up Cree XE-G Color 20mm LED Star - Optics Ready™

The INDUS XE-G Color LED Light Engine combines Cree’s compact 1.6 × 2.05mm XE-G emitter with an LEDdynamics thermally optimized aluminum MCPCB to deliver high optical density and precise beam control from a remarkably small source. Choose from 17 color and spectral options, including direct-color and phosphor-converted LEDs, for applications requiring precise wavelength selection, color mixing or spectral control. Optional HexaTherm™ technology enhances thermal performance, while the Optics Ready™ platform supports multiple beam distributions for straightforward optical integration.

Recommended Applications: Architectural • Entertainment • Machine Vision • Scientific • Horticulture

Description

XLamp® Element G (XE-G) LEDs are a breakthrough solution for color-mixing lighting applications, offering high light output and full spectral control. With 17 different colors and a variety of white options, lighting manufacturers gain unprecedented flexibility to optimize their product's light output properties. The compact 2.05 x 1.6 mm footprint package includes industry-leading features like a large isolated thermal pad, ESD protection, and minimal spacing between the LED chip and the package edge. The consistent XE-G platform across all colors simplifies design reuse, enabling efficient application in directional lighting, indoor, architectural, entertainment, and aftermarket automotive settings.

LED Star MCPCB

We offer the XE-G LED in two metal core printed circuit board (MCPCB) versions: Indus a single (1-Up: 1 LED) and Pulsar triple (3-Up: 3 LEDs). The 1-Up is a single XE-G LED reflow soldered to a 20mm hexagonal (LED Star) MCPCB. The MCPCB has four large solder pads for easy solder connections. The 3-Up is three (3) XE-G LEDs reflow soldered in-series to a 20mm hexagonal MCPCB. The 3-Up MCPCB has two solder pads for connections, mounting holes for compatible secondary optics and a center hole for wires or securing the LED star to a heat sink.

Correlated Color Temperatures (CCT)

The XE-G LED is offered here in Cool-White (5000K), Neutral-White (4000K) and Warm-White (3000K & 2700K).

Optics Ready™ — Choose Your Beam

The Optics Ready™ platform brings together secondary optics from Fusion Optix, Carclo, Khatod and other leading manufacturers. Optic and holder compatibility varies by LED emitter and board configuration. Choose from the compatible accessories listed for this product, or contact our solutions team to confirm the right optic and beam for your application.

Images, Part Numbers & Notes

Selecting the LED options near the 'add to cart' button displays the corresponding product image and part number. For referencing detailed specifications there are tables and downloadable documentation below.  Important Note: Unless noted otherwise the specifications listed are for a single XE-G LED. This means that in most cases the values need to be tripled for applications with the 3-Up version. For Example, if the forward voltage listed is 3.15V @ 350mA, then the 3-Up version would be 9.45V.

Technical Documenataion

WHITE CHARACTERISTICS WHITE (T_J= 85° C)

Color CHARACTERISTICS COLOR (T_J= 25° C)

Full Documentation

Cree XE-G Documentation
